March 17, 2017

How to build a Real-Time Chat with GraphQL Subscriptions and Apollo 🌍

In this tutorial, we explain how to build a chat application where the users can see their own and the locations of the other participants on a map. Not only the chat, but also the locations on the map get updated in realtime using GraphQL subscriptions.

Note: This tutorial is outdated and will be updated soon.

In this tutorial, we explain how to build a chat application where the users can see their own and the locations of the other participants on a map. Not only the chat, but also the locations on the map get updated in realtime using GraphQL subscriptions.

The tutorial focusses on the implementation on the client-side, to learn how you can implement subscriptions in your own GraphQL server, check out this tutorial.

You can check out a hosted demo of the application here.

Note: If you’re just getting started with GraphQL, check out the How to GraphQL fullstack tutorial for a holistic and in-depth learning experience.

What are GraphQL Subscriptions?

Subscriptions are a GraphQL feature that allow to get realtime updates from the database in a GraphQL backend. You set them up by subscribing to changes that are caused by specific mutations and then execute some code in your application to react to that change.

Using the Apollo client, you can benefit from the full power of subscriptions. Apollo implements subscriptions based on web sockets.

The simplest way to get started with a subscription is to specify a callback function where the modified data from the backend is provided as an argument. In a fully-fledged chat application where you’re interested in any changes on the Message type, which is either that a new message has been sent, that an existing message was modified or an existing message was deleted this could look as follows:

// subscribe to `CREATED`, `UPDATED` and `DELETED` mutations
this.newMessageObserver = this.props.client.subscribe({
  query: gql`
    subscription {
      Message {
        mutation # contains `CREATED`, `UPDATED` or `DELETED`
        node {
          text
          sentBy {
            name
          }
        }
      }
    }
  `,
  }).subscribe({
      next(data) {
      console.log('A mutation of the following type happened on the Message type: ', data.Message.mutation)
      console.log('The changed data looks as follows: ', data.Message.node)
    },
    error(error) {
      console.error('Subscription callback with error: ', error)
    },
})

Note: This code assumes that you have configured and set up the ApolloClient and made it available in the props of your React component using withApollo. We'll explain how to setup the ApolloClient in just a bit.

Figuring out the Mutation Type

The kind of change that happened in the database is reflected by the mutation field in the payload which contains either of three values:

  • CREATED: for a node that was added
  • UPDATED: for a node that was updated
  • DELETED: for a node that was deleted

Getting Information about the changed Node

The node field in the payload allows us to retrieve information about the modified node. It is also possible to ask for the state that node had before the mutation, you can do so by including the previousValues field in the selection set:

subscription {
  Message {
    mutation # contains `CREATED`, `UPDATED` or `DELETED`
    # node carries the new values
    node {
      text
      sentBy {
        name
      }
    }
    # previousValues carries scalar values from before the mutation happened
    previousValues {
      text
    }
  }

Now you could compare the fields in your code like so:

next(data) {
  console.log('Old text: ', data.Message.previousValues.text)
  console.log('New text: ', data.Message.node.text)
}

If you specify previousValues for a CREATED mutation, this field will just be null. Likewise, the node for a DELETED mutation will be null as well.

Subscriptions with Apollo

Apollo uses the concept of an Observable (which you might be familiar with if you have worked with RxJS before) in order to deliver updates to your application.

Rather than using the updated data manually in a callback though, you can benefit from further Apollo features that conventiently allow you to update the local ApolloStore. We used this technique in our example Worldchat app and will explain how it works in the following sections.

Setting up your Graphcool backend

Note: Graphcool has been replaced by Prisma. Check out this tutorial to learn how you can setup a realtime GraphQL server with Prisma.

First, we need to configure our backend. In order to do so, you can use the following data model file that represents the data model for our application:

type Traveller {
  id: ID!
  createdAt: DateTime!
  updatedAt: DateTime!
  name: String!
  location: Location! @relation(name: "TravellerLocation")
  messages: [Message!]! @relation(name: "MessagesFromTraveller")
}
type Message {
  id: ID!
  createdAt: DateTime!
  updatedAt: DateTime!
  text: String!
  sentBy: Traveller!  @relation(name: "MessagesFromTraveller")
}
type Location {
  id: ID!
  createdAt: DateTime!
  updatedAt: DateTime!
  traveller: Traveller! @relation(name: "TravellerLocation")
  latitude: Float!
  longitude: Float!
}

Since the data model file is already included in this repository, all you have to do is download or clone the project and then use our CLI tool to create your project along with the specified schema:

git clone [https://github.com/graphcool-examples/react-graphql.git](https://github.com/graphcool-examples/react-graphql.git)
cd react-graphql/subscriptions-with-apollo-worldchat/
graphcool init --schema schema.graphql --name Worldchat

This will automatically create a project called Worldchat that you can now access in our console.

Setting up the Apollo Client to use Subscriptions

To get started with subscriptions in the app, we need to configure our instance of the ApolloClient accordingly. In addition to the GraphQL endpoint, we also need to provide a SubscriptionClient that handles the websocket connection between our app and the server. To find out more about how the SubscriptionClient works, you can visit the repository where it's implemented.

To use the websocket client in your application, you first need to add it as a dependency:

yarn add subscriptions-transport-ws

Once you’ve installed the package, you can instantiate the SubscriptionClient and the ApolloClient as follows:

import ApolloClient, { createNetworkInterface } from 'apollo-client'
import {SubscriptionClient, addGraphQLSubscriptions} from 'subscriptions-transport-ws'
import { ApolloProvider } from 'react-apollo'
// Create WebSocket client
const wsClient = new SubscriptionClient(`wss://subscriptions.graph.cool/v1/__PROJECT ID__`, {
  reconnect: true,
  connectionParams: {
    // Pass any arguments you want for initialization
  }
})
const networkInterface = createNetworkInterface({ uri: 'https://api.graph.cool/simple/v1/__PROJECT ID__' })
// Extend the network interface with the WebSocket
const networkInterfaceWithSubscriptions = addGraphQLSubscriptions(
  networkInterface,
  wsClient
)
const client = new ApolloClient({
  networkInterface: networkInterfaceWithSubscriptions,
})

Note: You can get the your PROJECT ID directly from our console. Select your project and navigate to Settings -> General.

Now, as usual, you will have to pass the ApolloClient as a prop to the ApolloProvider and wrap all components that you'd like to access the data that is managed by Apollo. In the case of our chat, this step looks as follows:

class App extends Component {
// ...
render() {
    return (
      <ApolloProvider client={client}>
        <WorldChat />
      </ApolloProvider>
    )
  }
}

You can view the full implementation here.

Building a Real-Time Chat with Subscriptions 💬

Let’s now look at how we implemented the chat feature in our application. You can refer to the actual implementation whenever you like.

All we need for the chat functionality is one query to retrieve all messages from the database and one mutation that allows us to create a new message:

const allMessages = gql`
  query allMessages {
    allMessages {
      id
      text
      createdAt
      sentBy {
        id
        name
      }
    }
  }
`
const createMessage = gql`
  mutation createMessage($text: String!, $sentById: ID!) {
    createMessage(text: $text, sentById: $sentById) {
      id
      text
      createdAt
      sentBy {
        id
        name
      }
    }
  }
`

When exporting the component, we’re making these two operations available to our component by wrapping them around it using Apollo’s higher-order compoment graphql:

export default graphql(createMessage, {name : 'createMessageMutation'})(
  graphql(allMessages, {name: 'allMessagesQuery'})(Chat)
)

We then subscribe for changes on the Message type, filtering for mutations of type CREATED.

Note: Generally, a mutation can take one of three forms: CREATED, UPDATED or DELETED. The subscription API allows to use a filter to specify which of these you'd like to subscribe to. If you don't specify a filter, you'll subscribe to all of them by default. It is also possible to filter for more complex changes, e.g. for UPDATED mutations, you could only subscribe to changes that happen on a specific field.*

// Subscribe to `CREATED`-mutations
this.createMessageSubscription = this.props.allMessagesQuery.subscribeToMore({
  document: gql`
    subscription {
      Message(filter: {
        mutation_in: [CREATED]
      }) {
        node {
          id
          text
          createdAt
          sentBy {
            id
            name
          }
        }
      }
    }
  `,
  updateQuery: (previousState, {subscriptionData}) => {
    const newMessage = subscriptionData.data.Message.node
    const messages = previousState.allMessages.concat([newMessage])
    return {
      allMessages: messages,
    }
  },
  onError: (err) => console.error(err),
})

Notice that we’re using a different method to subscribe to the changes compared the first example where we used subscribe directly on an instance of the ApolloClient. This time, we're calling subscribeToMore on the allMessagesQuery (which is available in the props of our compoment because we wrapped it with graphql before).

Next to the actual subscription that we’re passing as the document argument to subscribeToMore, we're also passing a function for the updateQuery parameter. This function follows the same principle as a Redux reducer and allows us to conveniently merge the changes that are delivered by the subscription into the local ApolloStore. It takes in the previousState which is the the former query result of our allMessagesQueryand the subscriptionData which contains the payload that we specified in our subscription, in our case that's the node that carries information about the new message.

From the Apollo docs: subscribeToMore is a convenient way to update the result of a single query with a subscription. The updateQuery function passed to subscribeToMoreruns every time a new subscription result arrives, and it's responsible for updating the query result.

Fantastic, this is all we need in order for our chat to update in realtime! 🚀

Final result of the Worldchat app. [Demo can be found here.](https://demo.graph.cool/worldchat/)
Final result of the Worldchat app. [Demo can be found here.](https://demo.graph.cool/worldchat/)
Final result of the Worldchat app. Demo can be found here.

Adding Geo-Locations to the App 🗺

Let’s now look at how to add a geo-location feature to the app so that we can display the chat participants on a map. The full implementation is located here.

At first, we need one query that we use to initially retrieve all locations and their associated travellers.

const allLocations = gql`
  query allLocations {
    allLocations {
      id
      latitude
      longitude
      traveller {
        id
        name
      }
    }
  }
`

Then we’ll use two different mutations. The first one is a nested mutation that allows us to initially create a Location along with a Traveller, rather than having to do this in two different requests:

const createLocationAndTraveller = gql`
  mutation createLocationAndTraveller($name: String!, $latitude: Float!, $longitude: Float!) {
    createLocation(latitude: $latitude, longitude: $longitude, traveller: {
      name: $name
    }) {
      id
      latitude
      longitude
      traveller {
        id
        name
      }
    }
  }
`

We also have a simpler mutation that will be fired whenever a traveller logs back in to the system and we update their location:

const updateLocation = gql`
  mutation updateLocation($locationId: ID!, $latitude: Float!, $longitude: Float!) {
    updateLocation(id: $locationId, latitude: $latitude, longitude: $longitude) {
      traveller {
        id
        name
      }
      id
      latitude
      longitude
    }
  }
`

Like before, we’re wrapping our component before exporting it using graphql:

export default graphql(allLocations, {name: 'allLocationsQuery'})(
    graphql(createTravellerAndLocation, {name: 'createTravellerAndLocationMutation'})(
      graphql(updateLocation, {name: 'updateLocationMutation'})(WorldChat)
  )
)

Finally, we need to subscribe to the changes on the Location type. Every time a new traveller and location are created or an existing traveller updates their location, we want to reflect this on the map.

However, in the second case when an existing traveller logs back in, we actually only want to receive a notification if their location is different from before, that is either latitude or longitude or both have to be changed through the mutation. We'll include this requirement in the subscription using a filter again:

this.locationSubscription = this.props.allLocationsQuery.subscribeToMore({
  document: gql`
    subscription {
      Location(filter: {
        OR: [{
          mutation_in: [CREATED]
        }, {
          AND: [{
            mutation_in: [UPDATED]
          }, {
            updatedFields_contains_some: ["latitude", "longitude"]
          }]
        }]
      }) {
        mutation
        node {
          id
          latitude
          longitude
          traveller {
            id
            name
          }
        }
      }
    }
  `,
  updateQuery: (previousState, {subscriptionData}) => {
    // ... we'll take a look at this in a second
  }
})

Let’s try to understand the filter step by step. We want to get notified in either of two cases:

  • A new location was CREATED, the condidition that we specified for this is simply: mutation_in: [CREATED]

  • An existing location was UPDATED, however, there must have been a change in the latitude and/or longitude fields. We express this as follows:

    AND: [{
    mutation_in: [UPDATED]
    }, {
    updatedFields_contains_some: ["latitude", "longitude"]
    }]


We’re then putting these two cases together connecting them with an OR:

OR: [
        {
            mutation_in: [CREATED]
        },
        {
            AND: [
                {
                    mutation_in: [UPDATED]
                },
                {
                    updatedFields_contains_some: ["latitude", "longitude"]
                }
            ]
        }
]

Now, we only need to specify what should happen with the data that we receive through the subscription — we can do so using the updateQueries argument of subscribeToMoreagain:

this.locationSubscription = this.props.allLocationsQuery.subscribeToMore({
  document: gql`
    // ... see above for the implementation of the subscription
  `,
  updateQuery: (previousState, {subscriptionData}) => {
    if (subscriptionData.data.Location.mutation === 'CREATED') {
      const newLocation = subscriptionData.data.Location.node
      const locations = previousState.allLocations.concat([newLocation])
      return {
        allLocations: locations,
      }
    }
    else if (subscriptionData.data.Location.mutation === 'UPDATED') {
      const updatedLocation = subscriptionData.data.Location.node
      const locations = previousState.allLocations.concat([updatedLocation])
      const oldLocationIndex = locations.findIndex(location => {
        return updatedLocation.id === location.id
      })
      locations[oldLocationIndex] = updatedLocation
      return {
        allLocations: locations,
      }
    }
    return previousState
  }
})

In both cases, we’re simply incorporating the changes that we received from the subscription and specify how they should be merged into the ApolloStore. In the CREATED-case, we just append the new location to the existing list of locations. In the UPDATED-case, we replace the old version of that location in the ApolloStore.

Summing Up

In this tutorial, we’ve only scratched the surface of what you can do with our subscription API. To see what else is possible, you can check out our documentation.
