# PostgreSQL (/docs/orm/v6/overview/databases/postgresql) Location: ORM > v6 > Core Concepts > Supported databases > PostgreSQL The PostgreSQL data source connector connects Prisma ORM to a [PostgreSQL](https://www.postgresql.org/) database server. By default, the PostgreSQL connector contains a database driver responsible for connecting to your database. You can use a [driver adapter](/orm/v6/overview/databases/database-drivers#driver-adapters) (Preview) to connect to your database using a JavaScript database driver from Prisma Client. > [!NOTE] > Need a Postgres instance yesterday? > > With [Prisma Postgres](https://www.prisma.io/postgres?utm_source=docs\&utm_campaign=postgresql) you can get a database running on bare-metal in three clicks. Connection pooling, query caching, and automated backups are all included. [Visit the Console](https://console.prisma.io?utm_source=docs\&utm_campaign=postgresql) to get started today. > > Want any even faster way to get started with Prisma Postgres? Just run `npx prisma init --db` in your terminal. 🚀 Example [#example] To connect to a PostgreSQL database server, you need to configure a [`datasource`](/orm/v6/prisma-schema/overview/data-sources) block in your [Prisma schema](/orm/v6/prisma-schema/overview): ```prisma title="schema.prisma" datasource db { provider = "postgresql" } ``` The `datasource` block specifies the `postgresql` data source connector. In Prisma ORM 7, the database connection URL is configured in [`prisma.config.ts`](/orm/v6/reference/prisma-config-reference): ```typescript title="prisma.config.ts" import { defineConfig, env } from "prisma/config"; import "dotenv/config"; export default defineConfig({ schema: "prisma/schema.prisma", datasource: { url: env("DATABASE_URL"), }, }); ``` This configuration uses an [environment variable](/orm/v6/prisma-schema/overview#accessing-environment-variables-from-the-schema) to provide the database connection URL. Using the node-postgres driver [#using-the-node-postgres-driver] As of [`v5.4.0`](https://github.com/prisma/prisma/releases/tag/5.4.0), you can use Prisma ORM with database drivers from the JavaScript ecosystem (instead of using Prisma ORM's built-in drivers). You can do this by using a [driver adapter](/orm/v6/overview/databases/database-drivers). For PostgreSQL, [`node-postgres`](https://node-postgres.com) (`pg`) is one of the most popular drivers in the JavaScript ecosystem. It can be used with any PostgreSQL database that's accessed via TCP. This section explains how you can use it with Prisma ORM and the `@prisma/adapter-pg` driver adapter. 1. Install the dependencies [#1-install-the-dependencies] First, install Prisma ORM's driver adapter for `pg`: #### npm ```bash npm install @prisma/adapter-pg ``` #### pnpm ```bash pnpm add @prisma/adapter-pg ``` #### yarn ```bash yarn add @prisma/adapter-pg ``` #### bun ```bash bun add @prisma/adapter-pg ``` 2. Instantiate Prisma Client using the driver adapter [#2-instantiate-prisma-client-using-the-driver-adapter] Now, when you instantiate Prisma Client, you need to pass an instance of Prisma ORM's driver adapter to the `PrismaClient` constructor: ```ts import "dotenv/config"; import { PrismaPg } from "@prisma/adapter-pg"; import { PrismaClient } from "../generated/prisma/client"; const connectionString = `${process.env.DATABASE_URL}`; const adapter = new PrismaPg({ connectionString }); const prisma = new PrismaClient({ adapter }); ``` Notice that this code requires the `DATABASE_URL` environment variable to be set to your PostgreSQL connection string. You can learn more about the connection string below. Notes [#notes] Specifying a PostgreSQL schema [#specifying-a-postgresql-schema] You can specify a [PostgreSQL schema](https://www.postgresql.org/docs/current/ddl-schemas.html) by passing in the `schema` option when instantiating `PrismaPg`: ```ts const adapter = new PrismaPg({ connectionString }, { schema: "myPostgresSchema" }); ``` Connection details [#connection-details] Connection URL [#connection-url] Prisma ORM follows the connection URL format specified by [PostgreSQL's official guidelines](https://www.postgresql.org/docs/current/libpq-connect.html#LIBPQ-CONNSTRING), but does not support all arguments and includes additional arguments such as `schema`. Here's an overview of the components needed for a PostgreSQL connection URL: Structure of the PostgreSQL connection URL Base URL and path [#base-url-and-path] Here is an example of the structure of the *base URL* and the *path* using placeholder values in uppercase letters: ``` postgresql://USER:PASSWORD@HOST:PORT/DATABASE ``` The following components make up the *base URL* of your database, they are always required: | Name | Placeholder | Description | | :------- | :---------- | :-------------------------------------------------------------------------------------------------------------- | | Host | `HOST` | IP address/domain of your database server, e.g. `localhost` | | Port | `PORT` | Port on which your database server is running, e.g. `5432` | | User | `USER` | Name of your database user, e.g. `janedoe` | | Password | `PASSWORD` | Password for your database user | | Database | `DATABASE` | Name of the [database](https://www.postgresql.org/docs/12/manage-ag-overview.html) you want to use, e.g. `mydb` | > [!NOTE] > You must [percentage-encode special characters](/orm/v6/reference/connection-urls#special-characters). Arguments [#arguments] A connection URL can also take arguments. Here is the same example from above with placeholder values in uppercase letters for three *arguments*: ``` postgresql://USER:PASSWORD@HOST:PORT/DATABASE?KEY1=VALUE&KEY2=VALUE&KEY3=VALUE ``` The following arguments can be used: | Argument name | Required | Default | Description | | :--------------------- | :------- | ---------------------- | ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------- | | `schema` | **Yes** | `public` | Name of the [schema](https://www.postgresql.org/docs/12/ddl-schemas.html) you want to use, e.g. `myschema` | | `connection_limit` | No | `num_cpus * 2 + 1` | Maximum size of the [connection pool](/orm/v6/prisma-client/setup-and-configuration/databases-connections/connection-pool) (Prisma ORM v6 and before) | | `connect_timeout` | No | `5` | Maximum number of seconds to wait for a new connection to be opened, `0` means no timeout | | `pool_timeout` | No | `10` | Maximum number of seconds to wait for a new connection from the pool, `0` means no timeout | | `sslmode` | No | `prefer` | Configures whether to use TLS. Possible values: `prefer`, `disable`, `require` | | `sslcert` | No | | Path of the server certificate. Certificate paths are [resolved relative to the `./prisma folder`](/orm/v6/prisma-schema/overview/data-sources#securing-database-connections) | | `sslrootcert` | No | | Path of the root certificate. Certificate paths are [resolved relative to the `./prisma folder`](/orm/v6/prisma-schema/overview/data-sources#securing-database-connections) | | `sslidentity` | No | | Path to the PKCS12 certificate | | `sslpassword` | No | | Password that was used to secure the PKCS12 file | | `sslaccept` | No | `accept_invalid_certs` | Configures whether to check for missing values in the certificate. Possible values: `accept_invalid_certs`, `strict` | | `host` | No | | Points to a directory that contains a socket to be used for the connection | | `socket_timeout` | No | | Maximum number of seconds to wait until a single query terminates | | `pgbouncer` | No | `false` | Configure the Engine to [enable PgBouncer compatibility mode](/orm/v6/prisma-client/setup-and-configuration/databases-connections/pgbouncer) | | `statement_cache_size` | No | `100` | Since 2.1.0: Specifies the number of [prepared statements](#prepared-statement-caching) cached per connection | | `application_name` | No | | Since 3.3.0: Specifies a value for the application\_name configuration parameter | | `channel_binding` | No | `prefer` | Since 4.8.0: Specifies a value for the channel\_binding configuration parameter | | `options` | No | | Since 3.8.0: Specifies command line options to send to the server at connection start | As an example, if you want to connect to a schema called `myschema`, set the connection pool size to `5` and configure a timeout for queries of `3` seconds. You can use the following arguments: ``` postgresql://USER:PASSWORD@HOST:PORT/DATABASE?schema=myschema&connection_limit=5&socket_timeout=3 ``` > [!WARNING] > Prisma ORM v7: Connection pool defaults have changed > > In Prisma ORM v7, [driver adapters](/orm/v6/overview/databases/database-drivers) are the default for relational databases. Connection pooling is now handled by the `pg` driver, which has **different defaults** than Prisma ORM v6: > > * **Connection timeout**: `0` (no timeout) vs. v6's `5s` > * **Idle timeout**: `10s` vs. v6's `300s` > > If you experience timeout issues after upgrading, you may need to configure your driver adapter to match v6 behavior. See the [connection pool guide](/orm/v6/prisma-client/setup-and-configuration/databases-connections/connection-pool#postgresql-using-the-pg-driver-adapter) for detailed configuration examples. Configuring an SSL connection [#configuring-an-ssl-connection] You can add various parameters to the connection URL if your database server uses SSL. Here's an overview of the possible parameters: * `sslmode=(disable|prefer|require)`: * `prefer` (default): Prefer TLS if possible, accept plain text connections. * `disable`: Do not use TLS. * `require`: Require TLS or fail if not possible. * `sslcert=`: Path to the server certificate. This is the root certificate used by the database server to sign the client certificate. You need to provide this if the certificate doesn't exist in the trusted certificate store of your system. For Google Cloud this likely is `server-ca.pem`. Certificate paths are [resolved relative to the `./prisma folder`](/orm/v6/prisma-schema/overview/data-sources#securing-database-connections) * `sslidentity=`: Path to the PKCS12 certificate database created from client cert and key. This is the SSL identity file in PKCS12 format which you will generate using the client key and client certificate. It combines these two files in a single file and secures them via a password (see next parameter). You can create this file using your client key and client certificate by using the following command (using `openssl`): ``` openssl pkcs12 -export -out client-identity.p12 -inkey client-key.pem -in client-cert.pem ``` * `sslpassword=`: Password that was used to secure the PKCS12 file. The `openssl` command listed in the previous step will ask for a password while creating the PKCS12 file, you will need to provide that same exact password here. * `sslaccept=(strict|accept_invalid_certs)`: * `strict`: Any missing value in the certificate will lead to an error. For Google Cloud, especially if the database doesn't have a domain name, the certificate might miss the domain/IP address, causing an error when connecting. * `accept_invalid_certs` (default): Bypass this check. Be aware of the security consequences of this setting. Your database connection URL will look similar to this: ``` postgresql://USER:PASSWORD@HOST:PORT/DATABASE?sslidentity=client-identity.p12&sslpassword=mypassword&sslcert=rootca.cert ``` Connecting via sockets [#connecting-via-sockets] To connect to your PostgreSQL database via sockets, you must add a `host` field as a *query parameter* to the connection URL (instead of setting it as the `host` part of the URI). The value of this parameter then must point to the directory that contains the socket, e.g.: `postgresql://USER:PASSWORD@localhost/database?host=/var/run/postgresql/` Note that `localhost` is required, the value itself is ignored and can be anything. > **Note**: You can find additional context in this [GitHub issue](https://github.com/prisma/prisma-client-js/issues/437#issuecomment-592436707). Type mapping between PostgreSQL and Prisma schema [#type-mapping-between-postgresql-and-prisma-schema] These two tables show the type mapping between PostgreSQL and Prisma schema. First [how Prisma ORM scalar types are translated into PostgreSQL database column types](#mapping-between-prisma-orm-scalar-types-and-postgresql-database-column-types), and then [how PostgreSQL database column types relate to Prisma ORM scalar and native types](#mapping-between-postgresql-database-column-types-to-prisma-orm-scalar-and-native-types). > Alternatively, see [Prisma schema reference](/orm/v6/reference/prisma-schema-reference#model-field-scalar-types) for type mappings organized by Prisma type. Mapping between Prisma ORM scalar types and PostgreSQL database column types [#mapping-between-prisma-orm-scalar-types-and-postgresql-database-column-types] The PostgreSQL connector maps the [scalar types](/orm/v6/prisma-schema/data-model/models#scalar-fields) from the Prisma ORM [data model](/orm/v6/prisma-schema/data-model/models) as follows to database column types: | Prisma ORM | PostgreSQL | | ---------- | ------------------ | | `String` | `text` | | `Boolean` | `boolean` | | `Int` | `integer` | | `BigInt` | `bigint` | | `Float` | `double precision` | | `Decimal` | `decimal(65,30)` | | `DateTime` | `timestamp(3)` | | `Json` | `jsonb` | | `Bytes` | `bytea` | Mapping between PostgreSQL database column types to Prisma ORM scalar and native types [#mapping-between-postgresql-database-column-types-to-prisma-orm-scalar-and-native-types] * When [introspecting](/orm/v6/prisma-schema/introspection) a PostgreSQL database, the database types are mapped to Prisma ORM types according to the following table. * When [creating a migration](/orm/v6/prisma-migrate/getting-started) or [prototyping your schema](/orm/v6/prisma-migrate/workflows/prototyping-your-schema) the table is also used - in the other direction. | PostgreSQL (Type \| Aliases) | Supported | Prisma ORM | Native database type attribute | Notes | | ------------------------------------------- | :-------: | ------------- | :--------------------------------------- | :----------------------------------------------------------------------------------------------------------------------------------------------------------------------------- | | `bigint` \| `int8` | ✔️ | `BigInt` | `@db.BigInt`\* | \*Default mapping for `BigInt` - no type attribute added to schema. | | `boolean` \| `bool` | ✔️ | `Bool` | `@db.Boolean`\* | \*Default mapping for `Bool` - no type attribute added to schema. | | `timestamp with time zone` \| `timestamptz` | ✔️ | `DateTime` | `@db.Timestamptz(x)` | | | `time without time zone` \| `time` | ✔️ | `DateTime` | `@db.Time(x)` | | | `time with time zone` \| `timetz` | ✔️ | `DateTime` | `@db.Timetz(x)` | | | `numeric(p,s)` \| `decimal(p,s)` | ✔️ | `Decimal` | `@db.Decimal(x, y)` | | | `real` \| `float`, `float4` | ✔️ | `Float` | `@db.Real` | | | `double precision` \| `float8` | ✔️ | `Float` | `@db.DoublePrecision`\* | \*Default mapping for `Float` - no type attribute added to schema. | | `smallint` \| `int2` | ✔️ | `Int` | `@db.SmallInt` | | | `integer` \| `int`, `int4` | ✔️ | `Int` | `@db.Int`\* | \*Default mapping for `Int` - no type attribute added to schema. | | `smallserial` \| `serial2` | ✔️ | `Int` | `@db.SmallInt @default(autoincrement())` | | | `serial` \| `serial4` | ✔️ | `Int` | `@db.Int @default(autoincrement())` | | | `bigserial` \| `serial8` | ✔️ | `Int` | `@db.BigInt @default(autoincrement()` | | | `character(n)` \| `char(n)` | ✔️ | `String` | `@db.Char(x)` | | | `character varying(n)` \| `varchar(n)` | ✔️ | `String` | `@db.VarChar(x)` | | | `money` | ✔️ | `Decimal` | `@db.Money` | | | `text` | ✔️ | `String` | `@db.Text`\* | \*Default mapping for `String` - no type attribute added to schema. | | `timestamp` | ✔️ | `DateTime` | `@db.TimeStamp`\* | \*Default mapping for `DateTime` - no type attribute added to schema. | | `date` | ✔️ | `DateTime` | `@db.Date` | | | `enum` | ✔️ | `Enum` | N/A | | | `inet` | ✔️ | `String` | `@db.Inet` | | | `bit(n)` | ✔️ | `String` | `@Bit(x)` | | | `bit varying(n)` | ✔️ | `String` | `@VarBit` | | | `oid` | ✔️ | `Int` | `@db.Oid` | | | `uuid` | ✔️ | `String` | `@db.Uuid` | | | `json` | ✔️ | `Json` | `@db.Json` | | | `jsonb` | ✔️ | `Json` | `@db.JsonB`\* | \*Default mapping for `Json` - no type attribute added to schema. | | `bytea` | ✔️ | `Bytes` | `@db.ByteA`\* | \*Default mapping for `Bytes` - no type attribute added to schema. | | `xml` | ✔️ | `String` | `@db.Xml` | | | Array types | ✔️ | `[]` | | | | `citext` | ✔️\* | `String` | `@db.Citext` | \* Only available if [Citext extension is enabled](/orm/v6/prisma-schema/data-model/unsupported-database-features#enable-postgresql-extensions-for-native-database-functions). | | `interval` | Not yet | `Unsupported` | | | | `cidr` | Not yet | `Unsupported` | | | | `macaddr` | Not yet | `Unsupported` | | | | `tsvector` | Not yet | `Unsupported` | | | | `tsquery` | Not yet | `Unsupported` | | | | `int4range` | Not yet | `Unsupported` | | | | `int8range` | Not yet | `Unsupported` | | | | `numrange` | Not yet | `Unsupported` | | | | `tsrange` | Not yet | `Unsupported` | | | | `tstzrange` | Not yet | `Unsupported` | | | | `daterange` | Not yet | `Unsupported` | | | | `point` | Not yet | `Unsupported` | | | | `line` | Not yet | `Unsupported` | | | | `lseg` | Not yet | `Unsupported` | | | | `box` | Not yet | `Unsupported` | | | | `path` | Not yet | `Unsupported` | | | | `polygon` | Not yet | `Unsupported` | | | | `circle` | Not yet | `Unsupported` | | | | Composite types | Not yet | n/a | | | | Domain types | Not yet | n/a | | | [Introspection](/orm/v6/prisma-schema/introspection) adds native database types that are **not yet supported** as [`Unsupported`](/orm/v6/reference/prisma-schema-reference#unsupported) fields: ```prisma title="schema.prisma" model Device { id Int @id @default(autoincrement()) name String data Unsupported("circle") } ``` Prepared statement caching [#prepared-statement-caching] A [prepared statement](https://www.postgresql.org/docs/current/sql-prepare.html) is a feature that can be used to optimize performance. A prepared statement is parsed, compiled, and optimized only once and then can be executed directly multiple times without the overhead of parsing the query again. By caching prepared statements, Prisma Client's [query engine](/orm/v6/more/internals/engines) does not repeatedly compile the same query which reduces database CPU usage and query latency. For example, here is the generated SQL for two different queries made by Prisma Client: ```sql SELECT * FROM user WHERE name = "John"; SELECT * FROM user WHERE name = "Brenda"; ``` The two queries after parameterization will be the same, and the second query can skip the preparing step, saving database CPU and one extra roundtrip to the database. Query after parameterization: ```sql SELECT * FROM user WHERE name = $1 ``` Every database connection maintained by Prisma Client has a separate cache for storing prepared statements. The size of this cache can be tweaked with the `statement_cache_size` parameter in the connection string. By default, Prisma Client caches `100` statements per connection. Due to the nature of pgBouncer, if the `pgbouncer` parameter is set to `true`, the prepared statement cache is automatically disabled for that connection. ## Related pages - [`Cloudflare D1`](https://www.prisma.io/docs/orm/v6/overview/databases/cloudflare-d1): Guide to Cloudflare D1 - [`CockroachDB`](https://www.prisma.io/docs/orm/v6/overview/databases/cockroachdb): Guide to CockroachDB - [`Database drivers`](https://www.prisma.io/docs/orm/v6/overview/databases/database-drivers): Learn how Prisma connects to your database using the built-in drivers and how you can use Prisma along with other JavaScript database drivers using driver adapters (Preview) - [`Microsoft SQL Server`](https://www.prisma.io/docs/orm/v6/overview/databases/sql-server): This page explains how Prisma can connect to a Microsoft SQL Server database using the Microsoft SQL Server database connector. - [`MySQL/MariaDB`](https://www.prisma.io/docs/orm/v6/overview/databases/mysql): This page explains how Prisma can connect to a MySQL or MariaDB database using the MySQL database connector.
